UDP Packet Loss During NAS Transfers: How to Diagnose and Fix It
Diagnose UDP packet loss during NAS transfers by comparing interface counters, capture drops and controlled tests before changing buffers or network settings.
To diagnose UDP packet loss during NAS transfers, first confirm that the affected file transfer actually uses UDP, then compare evidence from the sender and receiver during the same time window. A stalled copy, a rising interface counter and a packet missing from a capture can have different causes.
The useful question is where traffic stopped being processed: on the physical link, in a receiving host, in the capture tool or in the transfer application. That distinction determines whether to investigate a cable, receiver pressure, capture quality or the application itself.
Confirm the flow before counting loss
Identify the application, transfer direction, endpoint addresses and relevant ports. Check the application’s documentation and active connection rather than assuming that every NAS copy uses the protocol named in a separate monitoring alert. If the transfer uses TCP, UDP-specific buffer tuning is the wrong starting point.
UDP’s base specification does not guarantee delivery or duplicate protection. Applications can add recovery above UDP; QUIC adds reliable streams above UDP. Missing datagrams therefore do not automatically establish that a saved file is corrupt.
Record the application’s completion status and errors separately from network observations. Ping can help check reachability, but its ICMP probes do not measure the application’s UDP delivery.
Read changes in counters, not lifetime totals
Save readings immediately before and after the affected transfer. Record the start/end times, direction, interface, route and application version alongside them. A large total accumulated since boot does not establish that this run dropped packets; even a new increase may include unrelated traffic on the same interface.
On a Linux host with the supported tools available, the following read-only command lists interfaces and detailed statistics:
ip -s -s link showUse the interface carrying the transfer. NAS shells, drivers and monitoring interfaces differ; follow the device’s supported documentation if these statistics are unavailable. Do not install tools or change system settings merely to reproduce this example.
The Linux interface-statistics documentation distinguishes these counters. Treat their changes as clues, not a complete diagnosis:
| Signal during the transfer | What it suggests | Useful next check |
|---|---|---|
rx_crc_errors increases | The interface received frames with CRC errors | Compare the peer switch-port counters; inspect the cable, port and link |
rx_missed_errors increases | The device missed incoming packets because receive resources were unavailable | Inspect receiver load and driver/device statistics |
rx_dropped increases | Received packets were not processed; causes can include resources or filtering | Identify the counter’s driver meaning and correlate with the relevant flow |
| Wireshark reports capture drops | The capture process did not record every packet | Improve capture conditions before inferring loss from missing packets |
These counters can overlap. Linux’s older /proc/net/dev view combines some fields, including missed packets in its drop total; do not add displayed counters together as if they represented independent losses. Interface totals also cover more than one application.
Separate capture loss from network loss
Capture the relevant traffic at both endpoints when authorized and practical. Match the same time interval, direction and flow; compare identifiable datagrams or the application’s sequence information where available. A datagram visible at the sender and absent at the receiver narrows the investigation only if both captures are trustworthy. It does not identify a particular switch.
Wireshark’s own dropped-packet count measures capture loss. Wireshark’s explanation describes how packets can reach the capture host yet fail to reach the capturing process. Missing capture records can therefore resemble network loss. If the tool does not report capture-drop information, record that uncertainty rather than treating it as zero.
Compare this with the receiving application’s logs and any available socket-buffer statistics. Receiver buffer pressure is different from a bad cable, and a general interface drop count is not proof that a particular UDP socket overflowed.
Use iperf3 as a controlled path check
An iperf3 UDP test can help when both endpoints support it and the test is permitted on the shared network. ESnet’s iperf3 documentation defines -u for UDP, -b for target bitrate and -R for reversing direction. Its control connection still uses TCP, so connection failure alone does not establish blocked UDP data.
Start at a low agreed rate and increase it only within the available capacity and maintenance window. Record the rate, datagram size, duration, direction and both tool versions. Avoid unlimited-rate UDP tests: the test itself can create congestion. Compare the receiver’s loss report with endpoint counters collected over that same interval.
The result describes those test processes and conditions. It neither proves the file application lost data nor guarantees that a different workload will behave the same way. For the broader storage-versus-network investigation, use the long-distance transfer diagnostic guide instead of expanding this test into every possible bottleneck.
Choose one change from the evidence
If CRC errors rise on one link, inspect that connection and compare a known-good cable or port. If evidence points to receiver pressure, reduce competing work and review the application’s and NAS vendor’s buffer guidance. A larger buffer cannot repair a physical error or make a persistently overloaded receiver process data indefinitely.
When loss changes with direction, follow the receiving role: a computer-to-NAS copy makes the NAS the receiver; the reverse copy makes the computer the receiver. A wired-versus-wireless comparison or an alternate permitted route can narrow the path, but changes in load or endpoints must be recorded.
Keep the original configuration, change one variable and repeat under comparable conditions. Coordinate managed switch or firewall changes with its administrator. Avoid blanket MTU, VLAN or persistent system-buffer changes without evidence.
Finally, verify the file result independently of speed. Use the application’s integrity check or compare a cryptographic hash of the same stable file revision at each end. Record completion, integrity and counter changes together; a faster copy alone does not prove that the suspected loss was fixed.
